Welcome to Jinling Steel (Shandong) Group Co., Ltd.
K10 Ductile iron pipe
Classification :
Ductile iron pipe
Key Words:
Ductile iron pipe
The main components of ductile iron pipe include carbon, silicon, manganese, sulfur, phosphorus and magnesium, etc. Ductile iron pipe is made by adding spheroidizing agent in casting iron water to spheroidize the graphite and through high-speed centrifugal casting process. The spheroidization level is controlled at 1-3 levels, and the spheroidization rate is not less than 80%, thus improving the mechanical properties of the material.
| Model Number | K8,K9,K7 |
| Length | 6m,8m,10m,etc. |
| Application | pipeline |
| Shape | ROUND |
| Hardness | ≤230HB |
| Pipe Wall Thickness | 6.0-64mm |
| Pull Strength | ≥420MPa |
| Yield (≥MPa) | ≥300Mpa |
| Material | Ductile Iron |
| Type | Casting |
| Processing Service | Welding,Bending,Punching,Decoiling,Cutting |
| Product Name | Ductile Iron Pipe |
| Standard | GB/T13295-2019,ISO2531/2003,EN545,EN598, ASTM,etc. |
| Shape | Round |
| Technique | Centrifugal casting |
| Material | K8,K9,K10,K12,DN80,DN100,etc. |
| Nominal Diameter | DN80-DN2600mm |
| Wall Thickness | 6.0-64mm |
| Length | 6m,8m,10m,etc. |
| Interface Type | T type,K type,N1 type,S type,etc. |
| Elongation | ≥7% |
Application areas:
Urban water supply system : Ductile iron pipe can stably and efficiently transport a large amount of drinking water, and its good sealing reduces the leakage and waste of water resources. For example, ductile iron pipes are often used for the main pipelines that provide daily water supply to urban residents.
Sewage Discharge: Ductile iron pipe can withstand the erosion of chemicals in sewage and higher pressure, suitable for urban sewage discharge pipeline.
Gas transportation: Ductile iron pipe has better gas tightness and pressure resistance to ensure the safe transportation of gas, so it is also a common choice of pipe material in the city gas distribution network.
Agricultural irrigation: Ductile iron pipe can effectively transport water to farmland to meet the needs of agricultural irrigation. Its corrosion and pressure resistance make it an ideal choice for agricultural irrigation systems.
Industrial pipeline: Ductile iron pipe is widely used in chemical, petroleum, metallurgy, paper and other industries in the pipeline system, whether it is conveying corrosive media or high-temperature and high-pressure fluids, it is competent.
Municipal construction: In municipal construction, ductile iron pipe has become an indispensable part of water supply system, drainage system and water diversion pipe with its excellent performance.
Welcome to formulate.
Packing And Delivery
FACTORY APPEARANCE
The company has advanced production equipment and technical strength, adopts internationally advanced production technology and quality control system to ensure that each batch of steel can meet or exceed international standards. Equipped with a complete product production line, the main equipment includes cutting machines, bending machines, punching machines, water jet cutting machines, polishing machines, plate cutting machines, wire drawing machines, etc. Our products include carbon steel, stainless steel, steel pipes, steel coils, steel plates, building materials: bars, wires, spiral coils, round steel; pipes: seamless pipes, welded pipes; plates: cold and hot rolled plates/coils, thick plates, color coated plates (galvanized plates, color steel plates, galvanized aluminum steel), silicon steel, strip steel; steel sections: working channel steel, H steel, square steel, flat steel, ball flat steel; up to 72 kinds of steel, with a stock of more than 200,000 tons.
FACTORY APPEARANCE
Our products are complete in variety, sufficient in stock, of excellent quality, low in price and considerate in service. At the same time, we are also the designated supplier of many large enterprises, providing steel for major project renovations in many countries. At the same time, we have also established a professional international trade service team, with a global sales network. With many advantages, we cooperate with customers in North America, South America, Europe, Southeast Asia, the Middle East and Africa, and have established business in Peru, the Philippines, Russia, Ukraine, Belarus, Uzbekistan, Pakistan, Indonesia, Malaysia, South Africa and other places. Products are exported to more than 30 countries including Africa, Sri Lanka, Turkey, Vietnam, Laos, Brazil, Thailand, the Middle East, the United Arab Emirates, Morocco, Spain, the United States, New Zealand, Iran, etc.
